PITCH 1.25MM

產品介紹/Wire to Board Connector/Wire to Board ConnectorPITCH 1.25MM

T-DWRXXSE7TR-00

PITCH 1.25 Wire to Board Single Row S/T SMD

PITCH 1.25 Wire to Board Single Row S/T SMD

Rated Voltage: 125V AC/DC

Rated Current: 1A AC/DC

Contact Resistance: 20mohms max

Dielectric Withstanding: 500V AC

Plastic Material: PA9T ,UL94V-0,
Terminal :Brass

T-DWRXXRE7TR00

PITCH 1.25 Wire to Board Single Row R/A SMD

PITCH 1.25 Wire to Board Single Row R/A SMD

Rated Voltage: 125V AC/DC

Rated Current: 1A AC/DC

Contact Resistance: 20mohms max

Dielectric Withstanding: 500V AC

Plastic Material: PA9T ,UL94V-0,
Terminal :Brass

DSX-51251SA-XXP-ENT

PITCH 1.25 Wire to Board Single Row S/T DIP

PITCH 1.25 Wire to Board Single Row S/T DIP

Rated Voltage: 125V AC/DC

Rated Current: 1A AC/DC

Contact Resistance: 20mohms/Min

Dielectric Withstanding: 500V AC

Plastic Material: PA9T ,UL94V-0,
Terminal :Brass

DSX-51251R-XXP-CNT

PITCH 1.25 Wire to Board Single Row R/A DIP

PITCH 1.25 Wire to Board Single Row R/A DIP

Rated Voltage: 125V AC/DC

Rated Current: 1A AC/DC

Contact Resistance: 20mohms max

Dielectric Withstanding: 500V AC

Plastic Material: LCP ,UL94V-0,
Terminal :Brass

1-5021XXMSG-B

PITCH 1.25 Wire to Board Dual Row S/T SMD

PITCH 1.25 Wire to Board Dual Row S/T SMD

Rated Voltage: 250V AC/DC

Rated Current: 3A AC/DC

Contact Resistance: 20mohms max

Dielectric Withstanding: 500V AC

Plastic Material: PA6T ,UL94V-0,
Terminal :Brass

DSC-5011XXMRX-052X

PITCH 1.25 Wire to Board Single Row R/A SMD

PITCH 1.25 Wire to Board Single Row R/A SMD

Rated Voltage: 50V AC/DC

Rated Current: 1A AC/DC

Contact Resistance: 20mohms max

Dielectric Withstanding: 500V AC

Plastic Material: LCP ,UL94V-0,
Terminal :Phosphor Bronze

DSC-5011XXMSX-039X

PITCH 1.25 Single Row S/T SMD

PITCH 1.25 Single Row S/T SMD

Rated Voltage: 50V AC/DC

Rated Current: 1A AC/DC

Contact Resistance: 20mohms max

Dielectric Withstanding: 500V AC

Plastic Material: LCP ,UL94V-0,
Terminal :Phosphor Bronze
