產品介紹Product
產品介紹/Wire to Board Connector/Wire to Board ConnectorPITCH 4.2MM
1-5016XXST-A
PITCH 4.2MM WAFER 180°
PITCH 4.2MM WAFER 180°
Rated Voltage: 350V AC/DC
Rated Current: 7A AC/DC
Contact Resistance: 30 mohms/Min
Dielectric Withstanding: 1500V AC
Plastic Material:PA66，UL94V-2
Terminal : Brass
1-5016XXRT-A
PITCH 4.2MM WAFER 90°
PITCH 4.2MM WAFER 90°
Rated Voltage: 350V AC/DC
Rated Current: 7A AC/DC
Contact Resistance: 30 mohms/Min
Dielectric Withstanding: 1000V AC
Plastic Material:PA66，UL94V-2
Terminal : Brass
