產品介紹Product
產品介紹/Wire to Board Connector/Wire to Board ConnectorPITCH 1.5MM
1-5037XXMST-E
PITCH 1.5 Wire to Board Dual Row S/T SMD
PITCH 1.5 Wire to Board Dual Row S/T SMD Rated Voltage: 50V AC/DC Rated Current: 1A AC/DC Contact Resistance: 20mohms max Dielectric Withstanding: 500V AC Plastic Material: PA9T ,UL94V-0, |
1-5037XXMRT-B
PITCH 1.5 Wire to Board Single Row SMD R/A
PITCH 1.5 Wire to Board Single Row SMD R/A
Rated Voltage: 100V AC/DC
Rated Current: 1A AC/DC
Contact Resistance: 20mohms max
Dielectric Withstanding: 500V AC
Plastic Material: PA6T ,UL94V-0,
Terminal :Brass
DSX-51501S-XXP-ENTT
PITCH 1.5 Wire to Board Single Row S/T DIP
PITCH 1.5 Wire to Board Single Row S/T DIP
Rated Voltage: 50V AC/DC
Rated Current: 1A AC/DC
Contact Resistance: 20mohms max
Dielectric Withstanding: 500V AC
Plastic Material: PA9T ,UL94V-0,
Terminal :Brass
DSX-51501R-XXP-ANT
PITCH 1.5 Wire to Board Single Row R/A DIP
PITCH 1.5 Wire to Board Single Row R/A DIP
圖面下載
Rated Voltage: 50V AC/DC
Rated Current: 1A AC/DC
Contact Resistance: 20mohms max
Dielectric Withstanding: 500V AC
Plastic Material: PA66 ,UL94V-0,
Terminal :Brass
